| PartNumber | AG-320240A4FIQW-K9H-S(N)(R) |
| Brand | AMPIRE |
| Size | 5.7 |
| Application | IA |
| Resolution | 320×240 , QVGA |
| Composition | LCM |
| Brightness | |
| CR | |
| Colors | Monochrome |
| Backlight | WLED |
| Interface | CPU |
| Panel Brand | AMPIRE |
| Panel Model | AG-320240A4FIQW-K9H-S(N)(R) |
| Panel Type | FSTN-LCD , LCM |
| Panel Size | 5.7 inch |
| Display Mode | STN, Transflective |
| Active Area | 115.185×86.385 mm |
| Outline | 167×104.7×14.5 mm |
| Surface | |
| Contrast Ratio | |
| Display Colors | Monochrome |
| Response Time | 200/200 (Typ.)(Tr/Td) |
| Viewing Angle | 30/30/35/30 (Typ.)(CR≥10)(L/R/U/D) |
| Lamp Type | 1S6PWLEDWithout Driver |
| Signal Interface | 8-bit 6080/8080 parallel, 24 pins |
| Input Voltage | 5.0V (Typ.) |
| AG-320240A4FIQW-K9H-S(N)(R) | AMPIRE | 5.7 | 320×240 |
| KG057QV1CA-G000 | Kyocera | 5.7 | 320×240 |
| KS3224ASTT-FW-X2 | Kyocera | 5.7 | 320×240 |
| LM057QC1T01 | SHARP | 5.7 | 320×240 |
| LQ057Q3DG02 | SHARP | 5.7 | 320×240 |
| LQ057V3DG01 | SHARP | 5.7 | 640×480 |
| LQ057V3LG11 | SHARP | 5.7 | 640×480 |
| LQ6NC02 | SHARP | 5.7 | 240×240 |
| SH320240C | Other | 5.7 | 320×240 |
| T78AAVGTF0 | Other | 5.7 | 320×240 |
| AA104XD12--G1 | Mitsubishi | 10.4 | 1024×768 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| EL240.128.45 | Lumineq | 4.8 | 240×128 |
| G150XG03 V3 | AUO | 15.0 | 1024×768 |
| LM64P101R | SHARP | 7.2 | 640×480 |
| LQ121S1DG43 | SHARP | 12.1 | 800×600 |
| LTA104D182F | TOSHIBA | 10.4 | 800×600 |
| NL8048BC19-02 | NLT | 7.0 | 800×480 |
| TS104SAALC01-00 | Tianma | 10.4 | 800×600 |
| UG-9664HSWAG01 | WiseChip | 0.95 | 96×64 |
