N133GCA-GQ1


Brand
Innolux
Size
13.3
Application
Laptop
Resolution
2560×1600
Composition
LCM ,   a-Si TFT-LCD
Brightness
CR
1000:1
Colors
16.7M
Backlight
WLED
Interface
In Stock
4747
Specifications
PartNumber N133GCA-GQ1
BrandInnolux
Size13.3
ApplicationLaptop
Resolution2560×1600
CompositionLCM ,   a-Si TFT-LCD
Brightness
CR1000:1
Colors16.7M
BacklightWLED , 15K hours , With LED Driver
Interface
ManufacturerInnolux
Screen Size13.3 inch
Pixel Number2560(RGB)×1600   (WQXGA)  227PPI
Active Area(mm)286.08 × 178.8 (H×V)
Bezel Area(mm)-
Luminance300 (Typ.)(cd/m²)
Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Good View atSymmetry
Color Depth16.7M   100% sRGB
Outline ShapeSlim (PCBA Flat, T≤3.2mm)
Refresh Rate60Hz
Model NameN133GCA-GQ1 (CMN13B0)
Screen TypeLCM ,   a-Si TFT-LCD
ArrangementRGB Vertical Stripe
Outline(mm)291.08 × 195.3 × 2.4 (H×V×D)
TreatmentAntiglare, Hard coating (3H)
Contrast Ratio1000 : 1 (Typ.) (TM)
Work ModeAAS, Normally Black, Transmissive
Response11/9 (Typ.)(Tr/Td) ms
Used forLaptop
TouchscreenWithout
