PartNumber | N133HCE-GT3 |
Brand | Innolux |
Size | 13.3 |
Application | Laptop |
Resolution | 1920×1080 |
Composition | a-Si TFT-LCD, LCM |
Brightness | |
CR | 1500:1 |
Colors | 16.7M |
Backlight | WLED |
Interface | eDP |
Model | N133HCE-GT3 (CMN13A5) |
Diagonal Size | 13.3 inch |
Type | a-Si TFT-LCD, LCM |
Pixel Format | 1920(RGB)×1080 [FHD] 166PPI |
Configuration | RGB Vertical Stripe |
Active Area | 293.76(H)×165.24(V) mm |
Outline Dim. | 298.76(H)×176.24(V) ×4.1(D) mm |
Bezel Area | - |
Treatment | Antiglare, Hard coating (3H) |
Luminance | 300 cd/m² (Typ.) |
Contrast Ratio | 1500:1 (Typ.) (TM) |
View Direction | Symmetry |
Response Time | 16/14 (Typ.)(Tr/Td) |
Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
Operating Mode | AAS, Normally Black, Transmissive |
Support Color | 16.7M 100% sRGB |
Light Source | WLED , 15K hours , With LED Driver |
Form Style | Slim (PCBA Bent, T≤3.0mm) |
Designed For | Laptop |
Frame Rate | 60Hz |
Touch Panel | Without |
Interface Type | eDP (2 Lanes) , eDP1.3 , 30 pins Connector |
Power Supply | 3.3V (Typ.) |
Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
