| PartNumber | N133I6-L09 |
| Brand | Innolux |
| Size | 13.3 |
| Application | NBPC |
| Resolution | 1280(RGB)×800 , WXGA |
| Composition | LCM |
| Brightness | 290 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | CMO |
| Panel Model | N133I6-L09 8 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 13.3 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 286.08×178.8 mm |
| Outline | 307.87×203.2×3.68 mm |
| Shape Style | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| Surface | Glare (Haze 0%), Hard coating (3H) |
| Contrast Ratio | 600:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 3/7 (Typ.)(Tr/Td) |
| Viewing Angle | 70/70/55/55 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6 stringsWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 30 pins |
| Input Voltage | 3.3V (Typ.) |
| B133XTN01.0 | AUO | 13.3 | 1366×768 |
| G133I1-L02 | Innolux | 13.3 | 1280×800 |
| LTN133AT16-L01 | Samsung | 13.3 | 1280×800 |
| N133HSE-EB3 | Innolux | 13.3 | 1920×1080 |
| N133I1-L01 | Innolux | 13.3 | 1280×800 |
| N133I5-L01 | Innolux | 13.3 | 1280×800 |
| N133I6-L01 | Innolux | 13.3 | 1280×800 |
| N133I6-L09 | Innolux | 13.3 | 1280×800 |
| N133I6-L10 | Innolux | 13.3 | 1280×800 |
| N133I7-L01 | Innolux | 13.3 | 1280×800 |
| B140RW03 V1 | AUO | 14.0 | 1600×900 |
| HSD121PHW1-A03 | HannStar | 12.1 | 1366×768 |
| LP154WE3-TLA1 | LG Display | 15.4 | 1680×1050 |
| LP154WX4-TLA1 | LG Display | 15.4 | 1280×800 |
| LP173WF1-TLA2 | LG Display | 17.3 | 1920×1080 |
| LTD121EWUD | TOSHIBA | 12.1 | 1280×800 |
| LTN121AT02-A01 | Samsung | 12.1 | 1280×800 |
| LTN184KT01-S02 | Samsung | 18.4 | 1680×945 |
| N140BGE-EA3 | Innolux | 14.0 | 1366×768 |
| N141I3-L05 | Innolux | 14.1 | 1280×800 |
