| PartNumber | NE160QDM-NY3 |
| Brand | BOE |
| Size | 16.0 |
| Application | Laptop Gaming |
| Resolution | 2560(RGB)×1600, WQXGA, 188PPI |
| Composition | Oxide TFT-LCD , LCM |
| Brightness | 500 cd/m² (Typ.) |
| CR | 1200:1 |
| Colors | 1.06B |
| Backlight | 11S4P×2CN |
| Interface | |
| Panel Brand | BOE |
| Panel Size | 16.0" |
| Display Area | 344.678(W)×215.424(H) mm |
| Outline Size | 349.68(W)×224.42(H) ×4.6(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 1.06B 100% DCI-P3 |
| Frequency | 165Hz |
| Shape Style | Slim (PCBA Bent, T≤3.0mm) |
| Panel Model | NE160QDM-NY3 (BOE0986) |
| Panel Type | Oxide TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Display Mode | ADS, Normally Black, Transmissive |
| Response Time | 25 (Typ.)(Tr+Td); 3 (Typ.)(G to G)(OD) |
| Lamp Type | 11S4P×2CN WLED , 15K hours , With LED Driver |
| Touch Screen | Without |
| HSD160PHW1-B00 | HannStar | 16.0 | 1366×768 |
| LTN160AT01-A02 | Samsung | 16.0 | 1366×768 |
| LTN160AT01-A05 | Samsung | 16.0 | 1366×768 |
| LTN160AT01-F02 | Samsung | 16.0 | 1366×768 |
| LTN160AT01-W01 | Samsung | 16.0 | 1366×768 |
| LTN160AT02-N01 | Samsung | 16.0 | 1366×768 |
| LTN160AT03-001 | Samsung | 16.0 | 1366×768 |
| LTN160AT06-B01 | Samsung | 16.0 | 1366×768 |
| LTN160HT01-A02 | Samsung | 16.0 | 1920×1080 |
| LTN160HT02-001 | Samsung | 16.0 | 1920×1080 |
