| PartNumber | NL10276AC30-03 |
| Brand | NLT |
| Size | 15.0 |
| Application | DMPC |
| Resolution | 1024(RGB)×768 , XGA |
| Composition | LCM |
| Brightness | 200 cd/m² (Typ.) |
| CR | 200:1 |
| Colors | Full color |
| Backlight | CCFL |
| Interface | Analog |
| Panel Brand | NEC |
| Panel Model | NL10276AC30-03 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 15.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 304.128×228.096 mm |
| Outline | 350×265×20.5 mm |
| Surface | |
| Contrast Ratio | 200:1 (Typ.) |
| Display Colors | Full color , CIE193142% |
| Response Time | 15/40 (Typ.)(Tr/Td) |
| Viewing Angle | 55/55/50/45 (Typ.)(CR≥10)(L/R/U/D) |
| Lamp Type | 2 pcsCCFLEmbedded (Inverter) |
| Signal Interface | Analog RGB, 41 pins |
| Input Voltage | 12.0V (Typ.) |
