| PartNumber | NL10276AC30-07 |
| Brand | NLT |
| Size | 15.0 |
| Application | DMPC |
| Resolution | 1024(RGB)×768 , XGA |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 300:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | TTL |
| Panel Brand | NEC |
| Panel Model | NL10276AC30-07 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 15.0 inch |
| Display Mode | Normally Black, Transmissive |
| Active Area | 304.128×228.096 mm |
| Outline | 330×256×30 mm |
| Surface | Hard coating (2H) |
| Contrast Ratio | 300:1 (Typ.) |
| Display Colors | 16.7M (6-bit + Hi-FRC), CIE193160% |
| Response Time | 10/10 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 8 pcsCCFLEmbedded (Inverter) |
| Signal Interface | TTL (2 ch, 8-bit), 75 pins |
| Input Voltage | 5.0V (Typ.) |
