| PartNumber | NL128102BM29-05A |
| Brand | NLT |
| Size | 19.0 |
| Application | MD |
| Resolution | 1280(LCR)×1024 , SXGA |
| Composition | LCM |
| Brightness | 1000 cd/m² (Typ.) |
| CR | 900:1 |
| Colors | Grayscale |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | NEC |
| Panel Model | NL128102BM29-05A |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 19.0 inch |
| Display Mode | SA-SFT, Normally Black, Transmissive |
| Active Area | 376.32×301.056 mm |
| Outline | 404.2×330×25.55 mm |
| Surface | Antiglare, Hard coating (2H) |
| Contrast Ratio | 900:1 (Typ.) |
| Display Colors | Grayscale (8-bit) |
| Response Time | 18/17 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Voltage | 5.0V (Typ.) |
| RoHS: |
