| PartNumber | NL192108AC10-01D |
| Brand | NLT |
| Size | 9.0 |
| Application | IA |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 700:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | NLT |
| Panel Model | NL192108AC10-01D |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 9.0 inch |
| Display Mode | UA-SFT, Normally Black, Transmissive |
| Active Area | 198.72×111.78 mm |
| Outline | 214.6×130×9.6 mm |
| Surface | Antiglare (Haze 41%), Hard coating (2H), Antireflection |
| Contrast Ratio | 700:1 (Typ.) |
| Display Colors | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| Response Time | 13/12 (Typ.)(Tr/Td) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 6/8-bit), 50 pins |
| Input Voltage | 3.3V (Typ.) |
