| PartNumber | NL192108BC18-06F |
| Brand | NLT |
| Size | 15.6 |
| Application | Industrial Outdoor H |
| Resolution | 1920×1080 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 750:1 |
| Colors | 16.7M |
| Backlight | 4 strings WLED , 50K hours , No Driver |
| Interface | eDP |
| Manufacturer | NLT |
| Model Name | NL192108BC18-06F |
| Screen Size | 15.6 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 141PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 344.16 × 193.59 (H×V) |
| Outline(mm) | 363.8 × 215.9 × 16.2 (H×V×D) |
| Bezel Area(mm) | 347.55 × 196.75 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 1500 cd/m² (Typ.) |
| Contrast Ratio | 750 : 1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Response | 15/15 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | UA-SFT, Normally Black, Transmissive |
| Color Depth | 16.7M 40% NTSC |
| Mass | 1.05/1.15Kgs (Typ./Max.) |
| Used for | Industrial Outdoor High Brightness |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (2 Lanes) , HBR1 (2.7G/lane) , 40 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -40 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
