| PartNumber | NT156WHM-N42 V8.3 |
| Brand | BOE |
| Size | 15.6 |
| Application | Laptop |
| Resolution | 1366×768 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 520:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 15.6 inch |
| Pixel Format | 1366(RGB)×768 [WXGA] 100PPI |
| Active Area | 344.232(H)×193.536(V) mm |
| Bezel Area | - |
| Luminance | 220 cd/m² (Typ.) |
| View Direction | 6 o'clock |
| Viewing Angle | 45/45/20/40 (Typ.)(CR≥10) |
| Support Color | 262K 45% NTSC |
| Form Style | Slim (PCBA Flat, T≤3.2mm) |
| Frame Rate | 60Hz |
| Model | NT156WHM-N42 V8.3 (BOE06A5) |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 359.5(H)×223.8(V) ×3.2(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 520:1 (Typ.) (TM) |
| Response Time | 12 (Typ.)(Tr+Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED [9S4P] , 15K hours , With LED Driver |
| Designed For | Laptop |
| Touch Panel | Without |
| CLAA156WA12 | CPT | 15.6 | 1366×768 |
| LP156WH1-TLA3 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLQ2 | LG Display | 15.6 | 1366×768 |
| LQ156D1JX03 | SHARP | 15.6 | 3840×2160 |
| LTN156AT36-D01 | Samsung | 15.6 | 1366×768 |
| NT156WHM-N10 | BOE | 15.6 | 1366×768 |
| NT156WHM-N12 | BOE | 15.6 | 1366×768 |
| NT156WHM-N33 | BOE | 15.6 | 1366×768 |
| NT156WHM-N42 | BOE | 15.6 | 1366×768 |
| NT156WHM-N50 | BOE | 15.6 | 1366×768 |
