| PartNumber | NV116WHM-A23 |
| Brand | BOE |
| Size | 11.6 |
| Application | Laptop |
| Resolution | 1366(RGB)×768, WXGA, 135PPI |
| Composition | a-Si TFT-LCD , Assem |
| Brightness | 200 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 262K |
| Backlight | 6S4P |
| Interface | |
| Panel Brand | BOE |
| Panel Size | 11.6" |
| Display Area | 256.125(W)×144(H) mm |
| Outline Size | 287.7(W)×185.6(H) ×4.05(D) mm |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 262K 50% NTSC |
| Frequency | 60Hz |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Panel Model | NV116WHM-A23 (BOE0744) |
| Panel Type | a-Si TFT-LCD , Assembly |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Anti-Scatter, Hard coating (7H) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Display Mode | - |
| Response Time | 30 (Typ.)(Tr+Td) |
| Lamp Type | 6S4P WLED , 15K hours , With LED Driver |
| Touch Screen | PCAP, Optical Bonding |
| B116XAN03.0 HW3A | AUO | 11.6 | 1366×768 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| LP116WH1-TLP1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| M116NWR1 R1 | IVO | 11.6 | 1366×768 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| M116NWR6 R0 | IVO | 11.6 | 1366×768 |
| N116BGE-EB2 Rec.C3 | Innolux | 11.6 | 1366×768 |
| N116BGE-L42 | Innolux | 11.6 | 1366×768 |
