| PartNumber | NV116WHM-N42 |
| Brand | BOE |
| Size | 11.6 |
| Application | Laptop |
| Resolution | 1366×768 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 800:1 |
| Colors | 262K |
| Backlight | WLED , 15K hours , With LED Driver |
| Interface | |
| Manufacturer | BOE |
| Model Name | NV116WHM-N42 |
| Screen Size | 11.6 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1366(RGB)×768 (WXGA) 135PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 256.125 × 144 (H×V) |
| Outline(mm) | - |
| Luminance | - |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
| Response | 30 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 262K 50% NTSC |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
