| PartNumber | NV116WHM-T01 |
| Brand | BOE |
| Size | 11.6 |
| Application | Laptop |
| Resolution | 1366(RGB)×768, WXGA, 135PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 250 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 262K |
| Backlight | 8S3P |
| Interface | eDP |
| Panel Brand | BOE |
| Panel Model | NV116WHM-T01 (BOE0786) |
| Panel Size | 11.6" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 256.125(W)×144(H) mm |
| Bezel Opening | - |
| Outline Size | 278(W)×168.5(H) ×3.2(D) mm |
| Surface | Hard coating |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | ADS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Display Colors | 262K 51% NTSC |
| Lamp Type | 8S3P WLED , 15K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | On-Cell Touch |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Signal Interface | eDP (1 Lane) , eDP1.2 , HBR1 (2.7G/lane) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B116XTN01.0 HW1A | AUO | 11.6 | 1366×768 |
| LP116WF1-SPA1 | LG Display | 11.6 | 1920×1080 |
| LP116WH4-SLN2 | LG Display | 11.6 | 1366×768 |
| M116NWR6 R0 | IVO | 11.6 | 1366×768 |
| N116B6-L02 | Innolux | 11.6 | 1366×768 |
| N116BGE-L32 | Innolux | 11.6 | 1366×768 |
| N116BGE-L41 | Innolux | 11.6 | 1366×768 |
| N116HSE-EBC | Innolux | 11.6 | 1920×1080 |
| NT116WHM-N31 | BOE | 11.6 | 1366×768 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
