| PartNumber | PA050DS7N1 |
| Brand | E Ink |
| Size | 5.0 |
| Application | CNS |
| Resolution | 320(RGB)×234 |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 350:1 |
| Colors | Full color |
| Backlight | CCFL |
| Interface | Analog |
| Panel Brand | PVI |
| Panel Model | PA050DS7N1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 5.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 102.72×74.53 mm |
| Outline | 127.4×92.8 mm |
| Surface | Antiglare |
| Contrast Ratio | 350:1 (Typ.) |
| Display Colors | Full color |
| Response Time | 15/30 (Typ.)(Tr/Td) |
| Viewing Angle | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | TFT Specific Analog RGB, 20 pins |
| Input Voltage | 5.0/5.0/17.0/-15.0V (Typ.)(VCC/VDD/VGH/VGL) |
