| PartNumber | PA064XS2 |
| Brand | E Ink |
| Size | 6.4 |
| Application | CNS |
| Resolution | 320(RGB)×234 |
| Composition | LCM |
| Brightness | |
| CR | 350:1 |
| Colors | Full color |
| Backlight | CCFL |
| Interface | Analog |
| Panel Brand | PVI |
| Panel Model | PA064XS2 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 6.4 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 129.6×97.3 mm |
| Surface | |
| Contrast Ratio | 350:1 (Typ.) |
| Display Colors | Full color |
| Response Time | 15/25 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/40/55 (Typ.)(CR≥10)(L/R/U/D) |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | TFT Specific Analog RGB, 30 pins |
| Input Voltage | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL) |
