| PartNumber | PP047JC-02A |
| Brand | No Brand |
| Size | 4.7 |
| Application | Mobile Phone |
| Resolution | 750×1334 |
| Composition | LTPS TFT-LCD, CELL |
| Brightness | |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | |
| Model | PP047JC-02A |
| Diagonal Size | 4.7 inch |
| Type | LTPS TFT-LCD, CELL |
| Pixel Format | 750(RGB)×1334 325PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 58.5(H)×104.052(V) mm |
| Outline Dim. | 61.08(H)×110.43(V) ×0.35(D) mm |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating Mode | Normally Black, Transmissive |
| Plate Thickness | 0.18+0.18 mm |
| Transmittance | 5.5% (Typ.)(with Polarizer) |
| Support Color | 16.7M 67% NTSC |
| Light Source | No B/L |
| Weight | - |
| Designed For | Mobile Phone |
| Frame Rate | - |
| Touch Panel | Without |
| D-IC Detail | COG Built-in 1 source chips |
