| PartNumber | DMF50081NB-FW |
| Brand | Kyocera |
| Size | 4.7 |
| Application | IA |
| Resolution | 320×240 , QVGA |
| Composition | LCM |
| Brightness | |
| CR | 4:1 |
| Colors | Monochrome |
| Backlight | CCFL |
| Interface | Parallel Data |
| Panel Brand | OPTREX |
| Panel Model | DMF50081NB-FW |
| Panel Type | STN-LCD , LCM |
| Panel Size | 4.7 inch |
| Display Mode | STN, Transmissive |
| Active Area | 95.97×71.97 mm |
| Outline | 139×120 mm |
| Surface | |
| Contrast Ratio | 4:1 (Typ.) |
| Display Colors | Monochrome |
| Response Time | 100/360 (Typ.)(Tr/Td) |
| Viewing Angle | |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | Parallel Data (4-bit), 14 pins |
