| PartNumber | RV101FBB-N00 |
| Brand | BOE |
| Size | 10.1 |
| Application | 3D Printer |
| Resolution | 4920×2880, 564PPI |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | 0 cd/m² |
| CR | 400:1 |
| Colors | Monochrome |
| Backlight | No |
| Interface | eDP |
| Panel Brand | BOE |
| Panel Model | RV101FBB-N00 |
| Panel Size | 10.1" |
| Panel Type | a-Si TFT-LCD, CELL |
| Pixel Format | Rectangle |
| Display Area | 221.4(W)×129.6(H) mm |
| Bezel Opening | - |
| Outline Size | 227.43(W)×139.5(H) ×0.95(D) mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 400:1 (Min.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Display Mode | ADS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 35 (Max.)(Tr+Td) |
| Glass Depth | - |
| Transmissivity | 6.0% (Typ.) |
| Display Colors | Monochrome |
| Lamp Type | No B/L |
| Frequency | 60Hz |
| Touch Screen | Without |
| Driver IC | COGBuilt-in 4 source chips |
| Panel Weight | TBD |
| Signal Interface | eDP (4 Lanes) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 70 °C ; Storage Temp.: -10 ~ 80 °C |
