| PartNumber | ST7461D02-5 |
| Brand | CSOT |
| Size | 75 |
| Application | TV Sets |
| Resolution | 3840(RGB)×2160, UHD, 59PPI |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | 0 cd/m² |
| CR | 6000:1 |
| Colors | 1.07B |
| Backlight | No |
| Interface | USI-T |
| Panel Brand | CSOT |
| Panel Model | ST7461D02-5 |
| Panel Size | 75" |
| Panel Type | a-Si TFT-LCD, CELL |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 1650.24(W)×928.26(H) mm |
| Bezel Opening | - |
| Outline Size | 1662.24(W)×941.96(H) ×1.34(D) mm |
| Surface | Antiglare (Haze 2%), Hard coating (3H) |
| Contrast Ratio | 6000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | HVA, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 6.5 (Typ.)(G to G) |
| Glass Depth | 0.50+0.50 mm |
| Transmissivity | 5.5% (Typ.)(with Polarizer) |
| Display Colors | 1.07B 93% DCI-P3 |
| Lamp Type | No B/L |
| Frequency | 120Hz |
| Touch Screen | Without |
| Driver IC | COFBuilt-in 12 source chips |
| Panel Weight | 4.77Kgs (Typ.) |
| Signal Interface | USI-T , 192 pins Connector |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LTA750FF01 | Samsung | 75 | 3840×2160 |
| LTA750FJ01 | Samsung | 75 | 3840×2160 |
| LTA750HQ01 | Samsung | 75 | 1920×1080 |
| LTI750HF01 | Samsung | 75 | 1920×1080 |
| T750QVF01.0 | AUO | 75 | 3840×2160 |
| V750DK1-KS5 Rev.F8 | Innolux | 75 | 3840×2160 |
