| PartNumber | TFD60W12 |
| Brand | TOSHIBA |
| Size | 6.0 |
| Application | IA |
| Resolution | 320(RGB)×234 |
| Composition | LCM |
| Brightness | 280 cd/m² (Typ.) |
| CR | 80:1 |
| Colors | Full color |
| Backlight | CCFL |
| Interface | Analog |
| Panel Brand | TOSHIBA |
| Panel Model | TFD60W12 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 6.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 121.92×89.154 mm |
| Outline | 144×109.4 mm |
| Surface | |
| Contrast Ratio | 80:1 (Typ.) |
| Display Colors | Full color |
| Response Time | 70/40 (Max.)(Tr/Td) |
| Viewing Angle | 45/45/45/15 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | TFT Specific Analog RGB, 24 pins |
| Input Voltage | 5.0/13.0/23.0/-5.0V (Typ.)(VDD/VBB/VGG/VEE) |
