| PartNumber | TM018FDZ02 |
| Brand | Tianma |
| Size | 1.8 |
| Application | MPH |
| Resolution | 128(RGB)×160 |
| Composition | LCM |
| Brightness | 190 cd/m² (Typ.) |
| CR | 250:1 |
| Colors | 65K/262K |
| Backlight | WLED |
| Interface | SPI |
| Panel Brand | TIANMA |
| Panel Model | TM018FDZ02 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 1.8 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 28.032×35.04 mm |
| Outline | 34×45.83×2.85 mm |
| Surface | |
| Contrast Ratio | 250:1 (Typ.) |
| Display Colors | 65K/262K , CIE193158% |
| Response Time | 15/35 (Typ.)(Tr/Td) |
| Viewing Angle | 65/65/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| Lamp Type | 1S2PWLEDWithout Driver |
| Signal Interface | SPI, 14 pins |
| Input Voltage | 2.8/2.8V (Typ.)(VDDI/VDD) |
