| PartNumber | TM024HDHG04 |
| Brand | TIANMA |
| Size | 2.4 |
| Application | Handheld & PDA |
| Resolution | 240(RGB)×320, QVGA, 166PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | - |
| CR | 500:1 |
| Colors | - |
| Backlight | WLED |
| Interface | CPU |
| Panel Brand | TIANMA |
| Panel Model | TM024HDHG04 |
| Panel Size | 2.4" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 36.72(W)×48.96(H) mm |
| Bezel Opening | - |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Viewing Angle | 70/70/70/60 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | - |
| Response Time | 20 (Typ.)(Tr+Td) |
| Display Colors | |
| Lamp Type | WLED |
| Frequency | - |
| Touch Screen | Without |
| Panel Weight | - |
| Signal Interface | CPU FPC |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
