| PartNumber | TM070RDH10-43 |
| Brand | TIANMA |
| Size | 7.0 |
| Application | Industrial Digital P |
| Resolution | 800×480 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 500:1 |
| Colors | 262K/16.7M |
| Backlight | 3S8P WLED , 20K hours , No Driver |
| Interface | |
| Manufacturer | TIANMA |
| Model Name | TM070RDH10-43 |
| Screen Size | 7.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 800(RGB)×480 (WVGA) 134PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 154.08 × 85.92 (H×V) |
| Outline(mm) | 164.9 × 100 × 6 (H×V×D) |
| Bezel Area(mm) | 157.08 × 89.39 (H×V) |
| Treatment | Antiglare |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Good View at | 12 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K/16.7M 50% NTSC |
| Mass | 160g (Typ.) |
| Used for | Industrial Digital Photo Frame Portable DVD Player |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| A070SN02 V0 | AUO | 7.0 | 800×600 |
| HE070IA-04F | Innolux | 7.0 | 800×1280 |
| HSD070IDW1-A30 | HannStar | 7.0 | 800×480 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| TM070DDH02 | Tianma | 7.0 | 1024×600 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
