| PartNumber | TM070RDHG25 |
| Brand | TIANMA |
| Size | 7.0 |
| Application | Industrial |
| Resolution | 800(RGB)×480, WVGA, 134PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 262K |
| Backlight | 3S8P |
| Interface | |
| Panel Brand | TIANMA |
| Panel Size | 7.0" |
| Display Area | 154.08(W)×85.92(H) mm |
| Outline Size | 164.9(W)×100(H) ×8.1(D) mm |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) |
| Best View on | 6 o'clock |
| Display Colors | 262K 50% NTSC |
| Frequency | 60Hz |
| Weight | TBD |
| Panel Model | TM070RDHG25 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 157.08(W)×89.39(H) mm |
| Surface | Antiglare |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 15 (Typ.)(Tr+Td) |
| Lamp Type | 3S8P WLED , 20K hours , Without Driver |
| Touch Screen | Without |
