| PartNumber | TM070WA-22L06 |
| Brand | SANYO |
| Size | 7.0 |
| Application | CNS |
| Resolution | 480(RGB)×234 |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 100:1 |
| Colors | |
| Backlight | CCFL |
| Interface | Analog |
| Panel Brand | TORISAN |
| Panel Model | TM070WA-22L06 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 7.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 154.08×87.05 mm |
| Outline | 167×102 mm |
| Surface | Antiglare |
| Contrast Ratio | 100:1 (Min.) |
| Display Colors | |
| Response Time | 30/20 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/30/40 (Max.)(CR≥5)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcsCCFL |
| Signal Interface | TFT Specific Analog RGB, 24 pins |
| Input Voltage | 5.3/15.0/-14V (Typ.)(VSH/VGH/VGL) |
