| PartNumber | YXD101301000-60 |
| Brand | SEBO |
| Size | 10.1 |
| Application | CNS |
| Resolution | 1024(RGB)×600 , WSVGA |
| Composition | LCM |
| Brightness | 1000 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 16.2M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | SEBO |
| Panel Model | YXD101301000-60 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 10.1 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 222.72×125.28 mm |
| Outline | 235×149.2×6.3 mm |
| Surface | Antiglare |
| Contrast Ratio | 600:1 (Typ.) |
| Display Colors | 16.2M (6-bit + FRC), CIE193152% |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 60 pins |
| Input Voltage | 3.3/9.6/18/-6V (Typ.)(DVDD/AVDD/VGH/VGL) |
