| PartNumber | TM070RDSG08 |
| Brand | TIANMA |
| Size | 7.0 |
| Application | Industrial |
| Resolution | 800×480 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 500:1 |
| Colors | 262K/16.7M |
| Backlight | 10S3P WLED , 50K hours , With LED Driver |
| Interface | LVDS |
| Manufacturer | TIANMA |
| Screen Size | 7.0 inch |
| Pixel Number | 800(RGB)×480 (WVGA) 133PPI |
| Active Area(mm) | 152.4 × 91.44 (H×V) |
| Bezel Area(mm) | 155.4 × 94.44 (H×V) |
| Luminance | 500 cd/m² (Typ.) |
| Viewing Angle | 70/70/70/60 (Typ.)(CR≥10) |
| Good View at | - |
| Color Depth | 262K/16.7M 70% NTSC |
| Mass | 176g (Typ.) |
| Refresh Rate | 60Hz |
| Signal Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Model Name | TM070RDSG08 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 166.4 × 107.2 × 8.5 (H×V×D) |
| Treatment | Antiglare |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Work Mode | TN, Normally White, Transmissive |
| Used for | Industrial |
| Touchscreen | Without |
