| PartNumber | TM070RDSG12 |
| Brand | TIANMA |
| Size | 7.0 |
| Application | Industrial |
| Resolution | 800×480 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 262K/16.7M |
| Backlight | 7S3P WLED , 50K hours , With LED Driver |
| Interface | |
| Manufacturer | TIANMA |
| Model Name | TM070RDSG12 |
| Screen Size | 7.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 800(RGB)×480 (WVGA) 133PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 152.4 × 91.44 (H×V) |
| Outline(mm) | 167 × 106.3 × 9.8 (H×V×D) |
| Bezel Area(mm) | 154.4 × 93.44 (H×V) |
| Treatment | Antiglare |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 20 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | SFT, Normally Black, Transmissive |
| Color Depth | 262K/16.7M 70% NTSC |
| Mass | 175g (Typ.) |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
