| PartNumber | TM101DDHG05 |
| Brand | TIANMA |
| Size | 10.1 |
| Application | Industrial |
| Resolution | 1024×600 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 500:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 10.1 inch |
| Pixel Format | 1024(RGB)×600 [WSVGA] 117PPI |
| Active Area | 222.72(H)×125.28(V) mm |
| Bezel Area | - |
| Luminance | 1400 cd/m² (Typ.) |
| View Direction | 12 o'clock |
| Viewing Angle | 80/80/75/80 (Typ.)(CR≥10) |
| Support Color | 262K/16.7M 47% NTSC |
| Weight | - |
| Frame Rate | 60Hz |
| Model | TM101DDHG05 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 235(H)×143(V) ×7.8(D) mm |
| Treatment | Antiglare, Hard coating |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Response Time | 7/9 (Typ.)(Tr/Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED [14S3P] , 30K hours , W/O Driver |
| Designed For | Industrial |
| Touch Panel | Without |
| AM-1280800N1TZQW-T06H | AMPIRE | 10.1 | 1280×800 |
| B101EW05 V0 | AUO | 10.1 | 1280×800 |
| BT101IW02 V.0 | Innolux | 10.1 | 1024×600 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
| HSD101PFW2-C00 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-H00 | HannStar | 10.1 | 1280×800 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
