| PartNumber | TM104TDGP10 |
| Brand | TIANMA |
| Size | 10.4 |
| Application | Industrial |
| Resolution | 1024(RGB)×768, XGA, 123PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 1200:1 |
| Colors | 262K/16.7M |
| Backlight | 8S4P |
| Interface | LVDS |
| Panel Brand | TIANMA |
| Panel Size | 10.4" |
| Display Area | 210.432(W)×157.824(H) mm |
| Outline Size | 230(W)×175.8(H) ×9.06(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 262K/16.7M 50% NTSC |
| Frequency | 60Hz |
| Panel Weight | 430g (Typ.) |
| Signal Interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| Panel Model | TM104TDGP10 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 213.43(W)×160.82(H) mm |
| Surface | Antiglare |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Display Mode | SFT, Normally Black, Transmissive |
| Response Time | 35 (Typ.)(Tr+Td) |
| Lamp Type | 8S4P WLED , With LED Driver |
| Touch Screen | Without |
