| PartNumber | TM133CFSP02 |
| Brand | TIANMA |
| Size | 13.3 |
| Application | Laptop |
| Resolution | 3840×2160 |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | |
| CR | 200:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | eDP |
| Model | TM133CFSP02 |
| Diagonal Size | 13.3 inch |
| Type | a-Si TFT-LCD, CELL |
| Pixel Format | 3840(RGB)×2160 [UHD] 332PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 293.76(H)×165.24(V) mm |
| Outline Dim. | 297.56(H)×173.74(V) ×1.24(D) mm |
| Bezel Area | - |
| Treatment | Clear |
| Luminance | 0 cd/m² |
| Contrast Ratio | 200:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 35 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | SFT, Normally Black, Transmissive |
| Plate Thickness | 0.50+0.50 mm |
| Transmittance | - |
| Support Color | 16.7M |
| Light Source | No B/L |
| Form Style | - |
| Designed For | Laptop |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | eDP (4 Lanes) , eDP1.4 , 40 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
