| PartNumber | TT101WSQ-N10 |
| Brand | BOE |
| Size | 10.1 |
| Application | NBPC |
| Resolution | 1024(RGB)×600 , WSVGA |
| Composition | CELL |
| Brightness | 0 |
| CR | 600:1 |
| Colors | 262K |
| Backlight | No B/L |
| Interface | |
| Panel Brand | BOE |
| Panel Model | TT101WSQ-N10 |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 10.1 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 222.72×125.28 mm |
| Outline | 230.4×134.2 mm |
| Surface | |
| Transmissivity | 6.17% (Typ.)(with Polarizer) |
| Contrast Ratio | 600:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193155% |
| Response Time | 8 (Typ.)(Tr+Td) |
| Viewing Angle | 70/70/55/70 (Typ.)(CR≥10)(L/R/U/D) |
