| PartNumber | TV070WXM-NS0 |
| Brand | BOE |
| Size | 7.0 |
| Application | Pad & Tablet |
| Resolution | 800×1280 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | 5S4P WLED , 20K hours , No Driver |
| Interface | MIPI |
| Manufacturer | BOE |
| Model Name | TV070WXM-NS0 |
| Screen Size | 7.0 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 800(RGB)×1280 (WXGA) 215PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 94.2 × 150.72 (H×V) |
| Outline(mm) | 99.7 × 160.93 × 3.8 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Hard coating (3H), Antireflection |
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 900 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 30 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 16.7M 50% NTSC |
| Mass | 74.5g (Typ.) |
| Used for | Pad & Tablet |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | MIPI (4 data lanes) , 34 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: -20 ~ 60 °C |
