| PartNumber | TV080WUM-AK2 |
| Brand | BOE |
| Size | 8.0 |
| Application | Pad & Tablet |
| Resolution | 1200×1920 |
| Composition | Assembly , a-Si TF |
| Brightness | |
| CR | 850:1 |
| Colors | 16.7M |
| Backlight | 7S3P WLED , 15K hours , No Driver |
| Interface | MIPI |
| Manufacturer | BOE |
| Model Name | TV080WUM-AK2 |
| Screen Size | 8.0 inch |
| Screen Type | Assembly , a-Si TFT-LCD |
| Pixel Number | 1200(RGB)×1920 (WUXGA) 283PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 107.64 × 172.224 (H×V) |
| Outline(mm) | 122.2 × 210.95 × 3.95 (H×V×D) |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 850 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | - |
| Color Depth | 16.7M 63% NTSC |
| Mass | 130g (Max.) |
| Used for | Pad & Tablet |
| Refresh Rate | 60Hz |
| Touchscreen | PCAP, Optical Bonding |
| Signal Type | MIPI (4 data lanes) , 39 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: -20 ~ 60 °C |
