| PartNumber | TV080WXM-NS1 |
| Brand | BOE |
| Size | 8.0 |
| Application | Pad & Tablet |
| Resolution | 800×1280 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 1100:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Diagonal Size | 8.0 inch |
| Pixel Format | 800(RGB)×1280 [WXGA] 188PPI |
| Active Area | 107.64(H)×172.224(V) mm |
| Luminance | 530 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Support Color | 16.7M 87% NTSC |
| Weight | - |
| Frame Rate | 60Hz |
| Interface Type | MIPI (4 data lanes) , 34 pins Connector |
| Power Supply | 1.8/5.4/-5.4V (Typ.)(VDD1/PVDD/NVDD) |
| Environment | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -30 ~ 80 °C |
| Model | TV080WXM-NS1 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 114.65(H)×183.853(V) ×3.56(D) mm |
| Contrast Ratio | 1100:1 (Typ.) (TM) |
| Response Time | 30 (Typ.)(Tr+Td) |
| Operating Mode | ADS, Normally Black, Transmissive |
| Light Source | WLED [3 strings] , W/O Driver |
| Designed For | Pad & Tablet |
| Touch Panel | Without |
