| PartNumber | TV097FMM-LB0-1SP0 |
| Brand | BOE |
| Size | 9.7 |
| Application | Pad & Tablet |
| Resolution | 1280×1752 |
| Composition | a-Si TFT-LCD , Assem |
| Brightness | |
| CR | 1200:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Diagonal Size | 9.7 inch |
| Pixel Format | 1280(RGB)×1752 223PPI |
| Active Area | 145.344(H)×198.94(V) mm |
| Bezel Area | - |
| Luminance | 320 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Support Color | 16.7M 70% NTSC |
| Weight | 115g (Max.) |
| Frame Rate | 60Hz |
| Interface Type | MIPI (4 data lanes) , 45 pins Connector |
| Power Supply | 1.8/5.7/-5.7V (Typ.)(VDD/AVDD/AVEE) |
| Environment | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| Model | TV097FMM-LB0-1SP0 |
| Type | a-Si TFT-LCD , Assembly |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 150.344(H)×208.29(V) mm |
| Treatment | Clear, Hard coating |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Response Time | 35 (Max.)(G to G) |
| Operating Mode | - |
| Light Source | WLED [9S4P] , 15K hours , W/O Driver |
| Designed For | Pad & Tablet |
| Touch Panel | In-Cell Touch |
