| PartNumber | TV101WUM-NW1 |
| Brand | No Brand |
| Size | 10.1 |
| Application | Pad & Tablet |
| Resolution | 1200(RGB)×1920, WUXGA, 225PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 8S4P |
| Interface | MIPI |
| Panel Brand | No Brand |
| Panel Size | 10.1" |
| Display Area | 135.36(W)×216.576(H) mm |
| Outline Size | 142.76(W)×228.18(H) ×4.2(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 100% sRGB |
| Frequency | 60Hz |
| Panel Weight | TBD |
| Signal Interface | MIPI (4 data lanes) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
| Panel Model | TV101WUM-NW1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Clear, Hard coating |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | HADS, Normally Black, Transmissive |
| Response Time | 30 (Typ.)(Tr+Td) |
| Lamp Type | 8S4P WLED , Without Driver |
| Touch Screen | Without |
