| PartNumber | TV101WUM-NH0 |
| Brand | BOE |
| Size | 10.1 |
| Application | PAD |
| Resolution | 1200(RGB)×1920 , WUXGA |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Panel Brand | BOE |
| Panel Model | TV101WUM-NH0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 10.1 inch |
| Display Mode | ADS, Normally Black, Transmissive |
| Active Area | 135.36×216.576 mm |
| Outline | 143×227.93 mm |
| Surface | |
| Contrast Ratio | 900:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193170% |
| Response Time | 25 (Typ.)(Tr+Tf) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 8S4PWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 39 pins |
| Input Voltage | 3.3/3.8V (Typ.)(VDD/VBAT) |
