| PartNumber | TV101WUM-NX0 |
| Brand | BOE |
| Size | 10.1 |
| Application | Pad & Tablet |
| Resolution | 1200(RGB)×1920, WUXGA, 225PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | 8S4P |
| Interface | |
| Panel Brand | BOE |
| Panel Size | 10.1" |
| Display Area | 135.36(W)×216.576(H) mm |
| Outline Size | 141.5(W)×227.31(H) mm |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 100% sRGB |
| Frequency | 60Hz |
| Weight | 105g (Typ.) |
| Panel Model | TV101WUM-NX0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Clear, Hard coating |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| Display Mode | HADS, Normally Black, Transmissive |
| Response Time | 30 (Typ.)(Tr+Td) |
| Lamp Type | 8S4P WLED , Without Driver |
| Touch Screen | Without |
