| PartNumber | TV101WXM-NS0 |
| Brand | BOE |
| Size | 10.1 |
| Application | Pad & Tablet |
| Resolution | 1280(RGB)×800, WXGA, 149PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | - |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | 6 |
| Interface | LVDS |
| Panel Brand | BOE |
| Panel Size | 10.1" |
| Display Area | 216.96(W)×135.6(H) mm |
| Outline Size | 228.211(W)×148.86(H) ×4.59(D) mm |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 50% NTSC |
| Frequency | 60Hz |
| Panel Weight | 130g (Typ.) |
| Signal Interface | LVDS (1 ch, 8-bit) , 45 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 65 °C ; Storage Temp.: -40 ~ 80 °C |
| Panel Model | TV101WXM-NS0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Hard coating (2H), Antireflection |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| Display Mode | ADS, Normally Black, Transmissive |
| Response Time | 30 (Typ.)(Tr+Td) |
| Lamp Type | 6 strings WLED , Without Driver |
| Touch Screen | Without |
