| PartNumber | TV101WXM-NU5 |
| Brand | BOE |
| Size | 10.1 |
| Application | Pad & Tablet |
| Resolution | 800×1280 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 7S4P WLED , No Driver |
| Interface | |
| Manufacturer | BOE |
| Screen Size | 10.1 inch |
| Pixel Number | 800(RGB)×1280 (WXGA) 150PPI |
| Active Area(mm) | 135.36 × 216.576 (H×V) |
| Bezel Area(mm) | 137.76 × 220.076 (H×V) |
| Luminance | 400 (Typ.)(cd/m²) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 60% NTSC |
| Mass | 135g (Max.) |
| Refresh Rate | 60Hz |
| Model Name | TV101WXM-NU5 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 142.32 × 228.2 × 4.3 (H×V×D) |
| Treatment | - |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Work Mode | ADS, Normally Black, Transmissive |
| Response | 30 (Typ.)(Tr+Td) ms |
| Used for | Pad & Tablet |
| Touchscreen | Without |
