| PartNumber | TX20D202VM2BAA |
| Brand | HITACHI |
| Size | 8.0 |
| Application | Industrial |
| Resolution | 800×480 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 600:1 |
| Colors | 262K |
| Backlight | , No Driver |
| Interface | LVDS |
| Manufacturer | HITACHI |
| Model Name | TX20D202VM2BAA |
| Screen Size | 8.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 800(RGB)×480 (WVGA) 116PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 174 × 104.4 (H×V) |
| Outline(mm) | - |
| Bezel Area(mm) | - |
| Treatment | Antiglare |
| Luminance | - |
| Contrast Ratio | 600 : 1 (Typ.) (TM) |
| Viewing Angle | - |
| Response | - |
| Good View at | - |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K |
| Mass | - |
| Used for | Industrial |
| Signal Type | LVDS |
