| PartNumber | TX20D33VM2BAC |
| Brand | KOE |
| Size | 8.0 |
| Application | Industrial |
| Resolution | 800×480 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 600:1 |
| Colors | 262K |
| Backlight | WLED , 50K hours , No Driver |
| Interface | CMOS |
| Manufacturer | KOE |
| Screen Size | 8.0 inch |
| Pixel Number | 800(RGB)×480 (WVGA) 116PPI |
| Active Area(mm) | 174 × 104.4 (H×V) |
| Bezel Area(mm) | 187.0 × 108.4 (H×V) |
| Luminance | - |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) |
| Good View at | 6 o'clock |
| Color Depth | 262K |
| Mass | 160g |
| Refresh Rate | 60Hz |
| Signal Type | CMOS (1 ch, 6-bit) , 40 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| Model Name | TX20D33VM2BAC |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 189 × 120 × 8 (H×V×D) |
| Treatment | - |
| Contrast Ratio | 600 : 1 (Typ.) (TM) |
| Response | 20 (Typ.)(Tr+Td) ms |
| Work Mode | TN, Normally White, Transmissive |
| Used for | Industrial |
| Touchscreen | Without |
