| PartNumber | TX38D18VM2BAA |
| Brand | HITACHI |
| Size | 15.0 |
| Application | Industrial Outdoor H |
| Resolution | 1024×768 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 700:1 |
| Colors | 262K/16.7M |
| Backlight | 13S3P WLED , 50K hours , With LED Driver |
| Interface | |
| Manufacturer | HITACHI |
| Model Name | TX38D18VM2BAA |
| Screen Size | 15.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1024(RGB)×768 (XGA) 85PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 304.128 × 228.096 (H×V) |
| Outline(mm) | 326.5 × 253.5 × 12.03 (H×V×D) |
| Bezel Area(mm) | 307.4 × 231.3 (H×V) |
| Treatment | Antiglare |
| Luminance | 1100 cd/m² (Typ.) |
| Contrast Ratio | 700 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/70/70 (Typ.)(CR≥10) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Good View at | 12 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K/16.7M 59% NTSC |
| Mass | 1.10Kgs (Typ.) |
| Used for | Industrial Outdoor High Brightness |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 70 °C |
| AC150XA03 | Mitsubishi | 15.0 | 1024×768 |
| HV150UX1-100 | HYDIS | 15.0 | 1600×1200 |
| LK150V3GZ13Z | SHARP | 15.0 | 640×480 |
| LM150X08-A4K3 | LG Display | 15.0 | 1024×768 |
| LQ150X1LGN2 | SHARP | 15.0 | 1024×768 |
| LQ150X1LW73 | SHARP | 15.0 | 1024×768 |
| LTM15C423S | TOSHIBA | 15.0 | 1024×768 |
| TX38D12VC0CAA | KOE | 15.0 | 1024×768 |
| TX38D14VC0CAA | KOE | 15.0 | 1024×768 |
| TX38D18VM2BAA REV.B | KOE | 15.0 | 1024×768 |
