| PartNumber | TX43D21VC0CAA |
| Brand | JDI |
| Size | 17.0 |
| Application | DMPC |
| Resolution | 1280(RGB)×1024 , SXGA |
| Composition | LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | JDI |
| Panel Model | TX43D21VC0CAA |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 17.0 inch |
| Display Mode | IPS-Pro, Normally Black, Transmissive |
| Active Area | 337.92×270.336 mm |
| Outline | 368×306×20.4 mm |
| Surface | Antiglare, Hard coating (2H) |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 10/12 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 3 stringsWLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Voltage | 5.0V (Typ.) |
| LM170E03-TLB1 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ6 | LG Display | 17.0 | 1280×1024 |
| LTM170EU-L21 | Samsung | 17.0 | 1280×1024 |
| LTM170EX-L31 | Samsung | 17.0 | 1280×1024 |
| LTN170BT07-G01 | Samsung | 17.0 | 1440×900 |
| LTN170BT08-G01 | Samsung | 17.0 | 1440×900 |
| LTN170U1-L02 | Samsung | 17.0 | 1920×1200 |
| LTN170WU-L01 | Samsung | 17.0 | 1920×1200 |
| M170ETN01.1 | AUO | 17.0 | 1280×1024 |
| TX43D21VC0CAA | JDI | 17.0 | 1280×1024 |
| LM150X08-A4KD | LG Display | 15.0 | 1024×768 |
| LM238WF2-SSG2 | LG Display | 23.8 | 1920×1080 |
| LM260WU2-SLA2 | LG Display | 25.5 | 1920×1200 |
| M185BGE-L10 | Innolux | 18.5 | 1366×768 |
| M201EW02 V6 | AUO | 20.1 | 1680×1050 |
| M240HTD01.0 | AUO | 24.0 | 1920×1080 |
| MT185GW01 V.0 | Innolux | 18.5 | 1366×768 |
| MT185GW01 V.4 | Innolux | 18.5 | 1366×768 |
| MV236FHB-N10 | BOE | 23.6 | 1920×1080 |
| SVA190WX01TB | SVA-NEC | 19.0 | 1440×900 |
