| PartNumber | UMSH-8377MD-8T |
| Brand | Other |
| Size | 5.7 |
| Application | IA |
| Resolution | 640(RGB)×480 , VGA |
| Composition | LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | URT |
| Panel Model | UMSH-8377MD-8T |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 5.7 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 115.2×86.4 mm |
| Outline | 127×98.43×10.06 mm |
| Surface | |
| Contrast Ratio | 600:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 15/35 (Typ.)(Tr/Td) |
| Viewing Angle | 75/75/60/75 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
