PartNumber | V390HJ1-LE1 |
Brand | Innolux |
Size | 39 |
Application | LCTV |
Resolution | 1920(RGB)×1080 , FHD |
Composition | LCM |
Brightness | 300 cd/m² (Typ.) |
CR | 3500:1 |
Colors | 16.7M |
Backlight | WLED |
Interface | LVDS |
Panel Brand | CHIMEI INNOLUX |
Panel Model | V390HJ1-LE1 |
Panel Type | a-Si TFT-LCD , LCM |
Panel Size | 39 inch |
Display Mode | Super MVA, Normally Black, Transmissive |
Active Area | 853.92×480.33 mm |
Outline | 878.72×510.23 mm |
Surface | Antiglare (Haze 3.5%), Hard coating (3H) |
Contrast Ratio | 3500:1 (Typ.) |
Display Colors | 16.7M (8-bit), CIE193168% |
Response Time | 9.5 (Typ.)(G to G) |
Viewing Angle | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
Frequency | 60Hz |
Lamp Type | WLEDEmbedded (LED Driver) |
Signal Interface | LVDS (2 ch, 8-bit), 51 pins |
Input Voltage | 12.0V (Typ.) |
