V390HJ1-LE6


Brand
Innolux
Size
39
Application
LCTV
Resolution
1920×1080
Composition
LCM
Brightness
350
CR
3500:1
Colors
16.7M
Backlight
WLED
Interface
LVDS
In Stock
250
Specifications
PartNumber V390HJ1-LE6
BrandInnolux
Size39
ApplicationLCTV
Resolution1920(RGB)×1080 , FHD
CompositionLCM
Brightness350 cd/m² (Typ.)
CR3500:1
Colors16.7M
BacklightWLED
InterfaceLVDS
Panel BrandCHIMEI INNOLUX
Panel ModelV390HJ1-LE6
Panel Type a-Si TFT-LCD , LCM
Panel Size39 inch
Display ModeSuper MVA, Normally Black, Transmissive
Active Area853.92×480.33 mm
Outline873.32×501.63 mm
SurfaceAntiglare (Haze 1%), Hard coating (3H)
Contrast Ratio3500:1 (Typ.)
Display Colors16.7M (8-bit), CIE193168%
Response Time8.5 (Typ.)(G to G)
Viewing Angle88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
Frequency60Hz
Lamp TypeWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (2 ch, 8-bit), 51 pins
Input Voltage12.0V (Typ.)
