Brand
Innolux
Size
42
Application
LCTV
Resolution
1920×1080
Composition
LCM
Brightness
380
CR
5000:1
Colors
16.7M
Backlight
WLED
Interface
LVDS
In Stock
5247
Specifications
PartNumber V420HK1-LS5 Rev.C7
BrandInnolux
Size42
ApplicationLCTV
Resolution1920(RGB)×1080 , FHD
CompositionLCM
Brightness380 cd/m² (Typ.)
CR5000:1
Colors16.7M
BacklightWLED
InterfaceLVDS
Panel BrandCHIMEI INNOLUX
Panel ModelV420HK1-LS5 Rev.C7
Panel Type a-Si TFT-LCD , LCM
Panel Size42 inch
Display ModeSuper MVA, Normally Black, Transmissive
Active Area930.24×523.26 mm
Outline958.2×553.3 mm
SurfaceAntiglare (Haze 3.5%), Hard coating (3H)
Contrast Ratio5000:1 (Typ.)
Display Colors16.7M (8-bit), CIE193172%
Response Time6 (Typ.)(G to G)
Viewing Angle88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
Frequency120Hz (60Hz Input)
Lamp TypeWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (4 ch, 10-bit), 61 pins
Input Voltage12.0V (Typ.)
